Display Specifications

PANEL TYPE: a-Si active matrix TFT-LCD

ACTIVE AREA: 803.52 x 1428.48 mm in Portrait Orientation

NATIVE RESOLUTION: 2160 x 3840 RGB UHD Resolution 4K Ultra HD

PIXEL PITCH: 0.372(H) x 0.372(V) mm

COLOR: 1.07 Billion color, 10 bits

HORIZONTAL FREQ.: 244KHz ~ 280KHz

VERTICAL FREQ.: 95Hz ~ 104Hz(DVB/PAL), 108Hz ~ 122Hz(NTSC)

Brightness & Image Quality

BRIGHTNESS: 2500-3000 cd/m², 1152 Zone Local Dimming LED Array Backlight Enhanced High Brightness

CONTRAST RATIO: 1400:1, High Dynamic Contrast Ratio: 100,000:1

DIMMING: Auto-dimming by Light Sensor and Local Dimming

VIEWING ANGLE: 89/89/89/89 (178° L/R/U/D)

RESPONSE TIME: 5msec typical

Connectivity & Features

INTERFACE: HDMIx2, DP option

MEDIA PLAYER: Android OS12 option

REMOTE CONTROL: Support for Full OSD Features

OPERATING (OPTION): Mini PC: i5-6500 CPU 3.2GHz, 4-8GB DDR2, 128G SSD, 5 x USB ports, 1 x RJ45, WiFi option

TOUCH: 10 points PCAP option

Power & Accessories

OPERATING VOLTAGE: AC 100 ~ 240V 60/50Hz

POWER CONSUMPTION: 520W for 2500 nits, 600W for 3000 nits in average mode for each panel

STANDBY MODE: 10 Watt or less

ACCESSORIES: AC Power Cord, Remote Controller, HDMI cable x 1

Physical Specifications

DIMENSION: 2200(H) x 1110(W) x 320(D) mm (w/o basement)

WEIGHT: 285 Kg approx (without air-con)

ENCLOSURE: Waterproof IP65 Enclosure

COOLING: By cooling fans controlled by MCU for outdoor, 1200W air-conditioner option for harsh outdoor

FRONT PROTECTION: 3+3 AR vandal glass or 6mm AR vandal glass

Environmental Conditions

OPERATING TEMPERATURE: -20°C to 45°C, Wide temp. -30°C to 50°C (with cool/warm air-con) option

OPERATING HUMIDITY: 10% to 85%

STORAGE TEMPERATURE: -30°C to 60°C

STORAGE HUMIDITY: 5% to 90%

Warranty

WARRANTY: One Year
