Display Specifications

PANEL TYPE: a-Si active matrix TFT-LCD

ACTIVE AREA: 518.4 x 324.0 mm

NATIVE RESOLUTION: 1920 x 1200, VGA to WUXGA resolution

PIXEL PITCH: 0.270(H) x 0.270(V) mm

COLOR: 10 bits 1.07 Billion

BACKLIGHT TYPE: LED edge type

HORIZONTAL SCAN: 30-93KHz

ASPECT RATIO: 16:10

Brightness & Image Quality

BRIGHTNESS: 1000 cd/m², LED Backlight Enhanced

CONTRAST RATIO: 1000:1, Dynamic contrast ratio up to 10000:1

DIMMING: 1 – 100% auto dimming by + / – buttons

VIEWING ANGLE: 89/89/89/89 (Wide Viewing Angles 178 deg)

RESPONSE TIME: 5ms Tr, 7ms Tf

LIFETIME: 35,000 hrs typical

IMAGE IMPROVEMENT: Optical bonding treatment option

Connectivity & Features

INTERFACE: VGA, Composite, DVI, RS-232 for remote control

TOUCHSCREEN: 10 Points PCAP Touchscreen with USB Controller option

PROTECTIVE GLASS: Anti-Reflective Protective Glass

EMI SHIELDING: AR glass and ITO 8.6 ohm coating for EMI

Power & Operation

OPERATING VOLTAGE: 90-230 VAC, 28VDC option

POWER CONSUMPTION: 110 Watt for whole unit at 1000 nits

STANDBY MODE: 2 Watt or less

ACCESSORIES: AC Power cord, VGA and DVI cable

Physical Specifications

DIMENSION: 670(W) x 420(H) x 75(D) mm, without handle

WEIGHT: 15 Kg, 33lbs

ENCLOSURE: Alu milled front bezel, Alu sheet fold back cover

SAND/DUST PROTECTION: IP65 for front panel only IP65

Durability & Environmental

OPERATING TEMPERATURE: -10°C to 50°C, Wide temp. -35°C to 50°C with internal heater option

OPERATING HUMIDITY: 10% to 85%

STORAGE TEMPERATURE: -35°C to 65°C

STORAGE HUMIDITY: 5% to 95%

SHOCK RESISTANCE: MIL-STD-901D, Grade A, Class 1 Type A

VIBRATION RESISTANCE: MIL-STD-167-1, Type 1

Warranty

WARRANTY: 1 Year Warranty
